Power Supply (factory configured) |
AC in 220V/50Hz-60Hz |
|
8Ω Stereo RMS Power |
950W x 4 |
|
4Ω Stereo RMS Power |
1600W x 4 |
|
8Ω Bridged Mono Power |
2400W |
|
Frequency Response |
35Hz-20kHz |
|
S/N |
> 95 dB |
|
Input Impedance (balanced/unbalanced) |
20kΩ/10kΩ |
|
Class |
H / 2-tier |
|
Controls |
AC switch, Ch. 1,2,3 & 4 gain knobs |
|
Phase |
+ |
|
Input Connectors |
Female XLR and Male XLR |
|
Output Connectors |
4 speakon connectors and 4 pair binding posts |
|
Input Sensitivity |
0.775V / 1.0V / 1.44V |
|
LED Indicators (per channel) |
Clip/Limit, Signal, Protect, Active |
|
Cooling |
Front - to - back / 3DC fans |
|
Dimensions |
483mm x 98mm x 500mm |
|
Net weight/ Gross weight |
17.5kg /15.5kg |
|
Warranty |
24 months |
