Voltage Range |
AC in 120V-270V /50Hz-60Hz |
|
8Ω Stereo Peak Power |
1140W + 1140W |
|
4Ω Stereo Peak Power |
2100W + 2100W |
|
2Ω Stereo Peak Power |
3000W + 3000W |
|
8Ω Bridged Mono Peak Power |
3100W |
|
Frequency Response |
35Hz-20kHz |
|
S/N |
> 98 dB |
|
Damping Factor (35Hz-200Hz at 8Ω) |
> 350 |
|
Input Impedance (balanced/unbalanced) |
20kΩ/10kΩ |
|
Controls |
Ch. 1 & 2 power switch, Ch. 1 & 2 gain knobs |
|
Phase |
+ |
|
Input Connectors |
Female XLR and Male XLR |
|
Output Connectors |
2 speakon connectors, 2 output binding posts |
|
Input Sensitivity |
0.775V / 1.0V / 1.44V |
|
LED Indicators (per channel) |
Clip/Limit, Signal, Protect, Active |
|
Cooling |
Font - to - back / 6 DC fans |
|
Dimensions |
483mm x 98mm x 500mm |
|
Gross weight/ Net weigth |
17kg /15kg |
|
Warranty |
24 months |
