Power Supply (factory configured) |
AC in 220V/50Hz-60Hz |
|
8Ω Stereo RMS Power |
1300W + 1300W |
|
4Ω Stereo RMS Power |
2150W + 2150W |
|
2Ω Stereo Power |
2900W + 2900W (not recommended) |
|
8Ω Bridged Mono Power |
3800W |
|
4Ω Bridged Mono Power |
5500W (not recommended) |
|
Frequency Response |
35Hz-20kHz |
|
S/N |
> 93 dB |
|
Damping Factor (35Hz-200Hz at 8Ω) |
≥ 800 |
|
Input Impedance (balanced/unbalanced) |
20kΩ/10kΩ |
|
Class |
H / 2-tier |
|
Controls |
AC switch, Ch. 1 & 2 gain knobs |
|
Phase |
+ |
|
Input Connectors |
Female XLR and Male XLR |
|
Output Connectors |
2 speakon connectors and 2 pair binding posts |
|
Filter Storage |
144.000uF |
|
Input Sensitivity |
0.775V / 1.0V / 1.44V |
|
LED Indicators (per channel) |
Clip/Limit, Signal, Protect, Active |
|
Cooling |
Font - to - back / 4 DC fans |
|
Dimensions |
3RU 132 x 483 x 495mm |
|
Gross weight/ Net weigth |
40.5kg/ 37.5kg |
|
Warranty |
12 months |
