Power Supply (factory configured) |
AC in 220V/50Hz-60Hz |
8Ω Stereo RMS Power |
1000W x 4 |
4Ω Stereo RMS Power |
1650 x 4 |
8Ω Bridged Mono Power |
2500W |
Frequency Response |
35Hz-20kHz |
S/N |
> 93 dB |
Damping Factor (35Hz-200Hz at 8Ω) |
≥ 600 |
Input Impedance (balanced/unbalanced) |
20kΩ/10kΩ |
Class |
H / 2-tier |
Controls |
AC switch, Ch. 1,2,3 & 4 gain knobs |
Phase |
+ |
Input Connectors |
Female XLR and Male XLR |
Output Connectors |
4 speakon connectors and 4 pair binding posts |
Filter Storage |
144.000uF |
Input Sensitivity |
0.775V / 1.0V / 1.44V |
LED Indicators (per channel) |
Clip/Limit, Signal, Protect, Active |
Cooling |
Font - to - back / 4 DC fans |
Dimensions |
3RU 132 x 483 x 495mm |
Gross weight/ Net weigth |
39 kg / 37kg |
Warranty |
12 months |
