- Power Supply (factory configured) |
AC in 220V/50Hz-60Hz |
|
- 8Ω Stereo RMS Power |
1100W x 2 |
|
- 4Ω Stereo RMS Power |
1700W x 2 |
|
- 8Ω Bridged Mono Power |
3400W |
|
- Frequency Response |
35Hz-22kHz |
|
- Input Impedance: (balanced/ unbalanced) |
20kΩ (balanced) / 10kΩ (unbalanced) |
|
- Class |
H / 2-tier |
|
- Controls |
AC switch, CH.1 & 2 gain knobs |
|
- Input Connectors |
Female XLR and Male XLR |
|
- Output Connectors |
2 speakon connectors and 2 pair binding posts |
|
- Input Sensitivity |
0.775V / 1.0V / 1.44V |
|
- LED Indicators (per channel) |
Signal, Clip/Limit, Protect, Active |
|
- Cooling |
Font - to - back / 3 DC fans |
|
- Dimensions (Full size) |
483mm x 98mm x 400mm |
|
- Net weight |
10 kg |
|
- Gross weight |
12 kg |
|
- Phase |
+ |
