- Power Supply (factory configured) |
AC in 220V/50Hz-60Hz |
|
- 8Ω Stereo RMS Power |
High: 1550W x 4/ Low: 1000W x 4 |
|
- 4Ω Stereo RMS Power |
High: 2400W x 4/ Low: 1800W x 4 |
|
- 8Ω Bridged Mono Power |
High: 4800W x 2/ Low: 3600W x 2 |
|
- Peak output voltage |
158Vpeak |
|
- VPL, selectable |
158V, 128V |
|
- Frequency Response |
20Hz-22kHz |
|
- Input Impedance: (balanced/ unbalanced) |
20kΩ (balanced) / 10kΩ (unbalanced) |
|
- Class |
D |
|
- Controls |
AC switch, CH.1,2,3 & 4 gain knobs |
|
- Input Connectors |
Female XLR and Male XLR |
|
- Output Connectors |
6 speakons |
|
- Input Sensitivity |
0.77V / 1.0V |
|
- LED Indicators (per channel) |
Active, Bridge, D.T, High Power, Signal, Clip/Limit, S.C |
|
- Cooling |
Font - to - back / 3 DC fans |
|
- Dimensions (Full size) |
483mm x 98mm x 350mm |
|
- Net weight |
9.5 kg |
|
- Gross weight |
10.7 kg |
|
- Warranty |
2 years |
