Power Supply (factory configured) |
AC in 220V/50Hz-60Hz |
|
8Ω Stereo RMS Power |
High: 2200W x 2/ Low: 1500W x 2 |
|
4Ω Stereo RMS Power |
High: 3400W x 2/ Low: 2600W x 2 |
|
8Ω Bridged Mono Power |
High: 6800W/ Low: 5200W |
|
Peak output voltage |
188Vpeak |
|
VPL, selectable |
188V, 156V |
|
Frequency Response |
20Hz-22kHz |
|
Input Impedance (balanced/unbalanced) |
20kΩ (balanced) / 10kΩ (unbalanced) |
|
Class |
D |
|
Damping Factor |
>2000 @8Ω 20Hz-200Hz |
|
Input Connectors |
Female XLR and Male XLR |
|
Output Connectors |
3 speakons |
|
Input Sensitivity |
0.77V / 1.0V |
|
LED Indicators (per channel) |
Active, Bridge, D.T, High Power, Signal, Clip/Limit, S.C |
|
Controls |
AC switch, Ch. 1 & 2 gain knobs |
|
Cooling |
Font - to - back / 3 DC fans |
|
Dimensions |
483mm x 98mm x 350mm |
|
Net weigth |
9 kg |
|
Gross weight |
10.2 kg |
|
Warranty |
2 years |
